| Camera |
| Resolution | 3840×2180 (8MP) |
| Effective pixels | 8294400 |
| Pixel size | 2.0µm |
| Image sensor | SC5236 |
| Imager type and size | 1/2.7″ CMOS |
| Optical zoom | n/a |
| Digital zoom | 20x on web browser & IPV NVR |
| Signal system | NTSC/PAL |
| Aspect ratio | 16:9 |
| Minimum illumination | color: 0.11Lux
B/W: 0.0032lux
IR: 0 lux |
| Day night type | IR cut filter auto switch |
| Electronic shutter range | auto/manual (1/1 – 1/10,000s) |
| High Dynamic Range (HDR) | yes (WDR) |
| Electronic Image Stabilization (EIS) | n/a |
| Encoding |
| Video compression | H.265 / H.264 / MJPEG |
Frame rate
(maximum) | 8MP(3840×2180);6MP(3072×2048), 5MP(2592×1944) ; @ 1-20fps settable |
| Bit rate control | low bit rate (LBR), variable bit rate (VBR), constant bit rate (CBR) in H.265/H.264 |
| Video streaming | up to 3 individually configured streams in H.265 / H.264 / MJPEG |
| Network |
| Protocols | UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, 802.1x, UPnP, HTTP, HTTPs, QoS |
| Security | IP Network Filter, Allow or Disallow from IPv4,IPv6 or MAC addresses, 802.1x |
| Communication interface | RJ45 10M/100M Ethernet interface |
| System compatibility | Onvif S / G compliant |
| Lens |
| Lens type | Motorized Zoom |
| Iris | auto-Iris |
| Focal length | 2.8-12mm |
| F-number | F1.4 |
| Horizontal field of view | 102.7°- 32.2° |
| Vertical field of view | 57.7°- 18.1° |
| Focus | Auto |
| Remote focus and zoom | Yes |
| IR illuminator |
| IR distance | 50m (164feet) night vision with Dual SMD IR LED array |
| Audio |
| Audio Input/Output | n/a |
| Streaming | n/a |
| Encoding | n/a |
| Alarm |
| Input | n/a |
| Output | n/a |
| Additional Features |
| Image settings | ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser. |
| Corridor mode | 90°, 180° |
| Built-in analytics | object removal detection, abnormal video signal detection, line crossing detection and intrusion detection |
| Event triggers | analytics, network failure detection, scense change detection |
| Event actions | etrigger snapshot, email,ftp upload |
| File upload | FTP, network share and email |
| Notifications | HTTP, FTP, email |
| Storage | Micro SD Storage up to 128GB, Local HDD storage via browser |
| Environmental |
| Ingress protection | IP67 |
| Vandal resistance proof | IK10 |
| Operating temperature | -22°F to 131°F [-30°C to 55°C] |
| Storage temperature | -4°F to 158°F [-20°C to 70°C] |
| Operating humidity | 90%RH non-condensing |
| Storage humidity | 90%RH non-condensing |
| Electrical |
| Input voltage | DC12V ± 10%, PoE (802.3af) |
| Current draw | 750mA at DC12V |
| Power | < 9W |
| Physical Characteristics |
| Dimensions | 141mm(H) x 100.2mm(ø) [5.55’ x 3.494] |
| Weight | 890g [1.96lb] |
| Connectors | Ethernet interface: RJ45 DC power terminal block |
| Finish | metal and acrylic |
| General |
| Safety/EMC standard | CE, FCC |
| Languages | English |
