CAM-IRZ-8Z-36X-IR

8 Megapixels resolution 36X optical zoom IR cut filter with auto switch H.264 / H.265 encoding IR illuminator 492ft [150m] Dual stream Tilt range 0° to 90° (Auto Flip) PoE or 24VAC power IP66 weather resistant Onvif compatible Local microSD cared storage 16X digital zoom WDR, DLS, BLC, DSS
Manufacturer: Aventura

Features

  • 8 Megapixels resolution
  • 36X optical zoom
  • IR cut filter with auto switch
  • H.264 / H.265 encoding
  • IR illuminator 492ft [150m]
  • Dual stream
  • Tilt range 0° to 90° (Auto Flip)
  • PoE or 24VAC power
  • IP66 weather resistant
  • Onvif compatible
  • Local microSD cared storage
  • 16X digital zoom
  • WDR, DLS, BLC, DSS

Part Numbers


CAM-IRZ-8Z-36X-IR8MP H.265/H.264 36x IP Network PTZ Dual Head High PoE Camera w/150M IR

Specifications

Camera
Resolution3840×2160 (8MP)
Effective pixels8,294,400
Image sensorprogressive scan
Imager type and size1/2.8″ CMOS
Optical zoom36x
Signal systemNTSC/PAL
Aspect ratio16:9
Minimum illuminationColor: 0.05Lux @ (F1.2, AGC ON)
B/W: 0.05lux @ (F1.2, AGC ON)
IR: 0Lux
Day night typeIR cut filter auto switch or manual
Electronic shutter rangeauto/manual (1/50 – 1/10,000s)
Signal-to-Noise Ratio (SNR)≥ 50dB
Back light compensation (BLC)On/Off
Memory512MB RAM. 16MB Flash
Encoding
Video compressionH.264 / H.265 / MJPEG
Frame ratemain stream: 1920×1080 @ 1-30fps; 1280×720 @ 1-30fps
sub-stream: D1 @ 1-30 fps; 640×480 @ 1-30 fps; 320×240 @ 1-30 fps
Bit rate control30 to 32,768 Kb/s continuously adjustable; constant bit rate (CBR), constrained variable bit rate (CVBR) with configurable maximum value
Video streamingdouble streaming: unicast, multicast
Multi-view streaming2 individually cropped out view areas
Data streamingevent data
Network
ProtocolsIPV4, HTTP, FTP, SMTP, NTP, RTSP, RTP, TCP, UDP, DHCP
Communication interfaceRJ45 10M/100M Ethernet interface
System compatibilityOnvif v2.4
Users10 concurrent connections
Lens
Lens type300m auto focus
Irisauto
Focal length6mm -180mm
F-numberF1.4 to F4.0
Horizontal field of view59° to 2.4°
Vertical field of view36.0° to 2.1°
Focusauto
Minimum object distance0.1m to 1m
Remote focus and zoomyes
Pan/Tilt/Zoom (PTZ)yes
Illuminator
typeinfrared
Effective Range492ft [150m]
Pan/Tilt
Pan range360° continuous
Pan speedPan manual speed: 0.4° to 320°/s, Pan preset speed: 240°/s
Tilt range0° to 90° (Auto Flip)
Tilt speedTilt manual speed: 0.4° to 150°/s, Tilt preset speed: 240°/s
Position accuracy±0.025°
Proportional zoomauto-speed proportional to the length of focus
Presets128 with user titles
Patrol4 patrols, up to 16 presets per patrol
Pattern4 patterns, with the recording time not less than 3 minutes per pattern
Park actionpreset / patrol / pattern / pan scan / tilt scan / random scan / frame scan / panorama scan
ProtocolPelco-P, Pelco-D, self-adaptive
External ControlRS485 2400/4800/9600/19200 bps
Audio
Audio Input/Output1 input, 1 output
Streamingduplex
Inputline in/3.5mm jacks
EncodingG711A, G711U (16k)
Alarm
Input1 input screw terminals
Output1 PhotoMOS™ relay (30 V, 1 A) screw terminals
Triggersunsupervised mode that detects switch closures (N.O. and N.C.)
Additional Features
Image settingslens flip, angle flip, rotation 0° or 180°, defog mode, WDR, 16X digital zoom, BLC, slow shutter, digital image stabilization
Information displaytitle, preset, pattern, scan, zone, zoom, alarm, date/time
Wide Dynamic Range (WDR)140dB
Gain controlAGC (8dB to 62dB)
White balance (range)auto/manual_(R-G-B)
Digital Noise Reduction (DNR)auto
Noise reduction3D DNR (0 to 5)
Event triggerssensor detection, motion detection
Event actionsemail / ftp
Presets128 with user titles
Text overlaytitle on/off
Application programming interfaceCGI
On-board storagemicroSD maximum 128GB
RS-485 inputscrew terminals
Environmental
Ingress protectionIP66
Vandal resistance proofIK10
Operating temperature-40°F to 158°F [-40°C to 70°C]
Storage temperature-31°F to 131°F [-35°C to 60°C]
Operating humidity100%RH condensing
Storage humidity100%RH condensing
Electrical
Input voltage24V AC/DC ± 10%
Current drawMax 2.1A @ 24VAC; 2.5A supply included
PowerMax 51W at device
Surge protectionBuilt-in TVS-4000V lightning resistant, surge resistant, switching transient resistant
Physical Characteristics
Dimensions16.18″”(W) x 10.6″”(H) x 8.26″”(D)
41.1cm(W) x 26.9cm(H) x 21cm(D)
Weight13.9lbs [6.3kg]
ConnectorsEthernet interface: RJ45
DC power
audio IN/OUT
alarm IN/OUT
reset button
RS-485
General
Safety/EMC standardCE, FCC
LanguagesEnglish
