DHE-16-ENT

Standard H.264 Embedded DVR Series Standard H.264 Embedded DVR Series DHE-ENT 16 Channel Digital Video Recorder Up to 16 Analog Video Channels Up to 960H Record Resolution H.264 Video Compression 2U Rackmount Chassis Up to 4TB Storage
Manufacturer: Aventura

Features

  • 256 camera recording to 8MP
  • 512 Mb/s bandwidth
  • H.264/H.265 support saves disk space
  • 16 hard drives for up to 160Tb storage
  • RAID 5/6 support for data protection
  • Intel® processor with 64 bit Linux OS
  • PC and smartphone clients for remote access
  • Redundant power supply for reliability

Specifications

Hardware
CPUIntel i5
RAM4GB
Video RAM1GB
StorageUp to 36 TB
OSWindows 7
Removable MediaDVD-RW
AUDIO/VIDEO
Processor1 VGA/ 2 HDMIOut
Video/Audio Inputs1 – 64 BNC(1.0Vp-p 75 Ω)
Video CompressionH.264
Audio CompressionOgg Vorbis 16 Kbps
COMMUNICATION
LANRedundant 10/100/1000
Record Rate30 fps @4CIF/1 Mbps, 15fps @4CIF/4 Mbps
Input Device106-KeyUSBKeyboard /Optical USBMouse
PTZ ControlRS-232/422 Interface
RESOLUTION
Video Display ResolutionAnalog: Up to 4CIF(NTSC: 704X480, PAL: 704×576)
Digital: Up to 2560 x1600
Recording ResolutionAnalog: Up to 4CIF(NTSC: 704X480, PAL: 704×576)
Digital: Up to 20 Megapixel
ENVIRONMENT
Operating Temperature25 ~ 110° F(-3.8 ~ 43.3° C)
ELECTRICAL
Power Supply500 W/ 90 – 264 V
GENERAL
Weight50 lbs (22.7 kg)
Dimensions7″ x 19″ x 20″(178 x 482 x 508 mm)
Chassis Type4URackmount
Encrypted WatermarkAES/ MD5
MonitoringFull Remote Control PSTN, ISDN, ADSL, LANand TCP/IP
Safety StandardsEN60950,UL1459
EMC StandardsEN55022 Class-B, EN50082-1
FCCFIPS140-2,USGCB
Warranty5 Years

Part Numbers


DHC-04H.264 hybrid DVR/NVR, 4ch Audio/Video, up to 16 IPVideo Channels, 2TBStorage,Optional RAID
DHC-08H.264 hybrid DVR/NVR, 8ch Audio/Video, up to 16 IPVideo Channels, 3TBStorage,Optional RAID
DHC-12H.264 hybrid DVR/NVR, 12ch Audio/Video, up to 16 IPVideo Channels, 4TBStorage,Optional RAID
DHC-16H.264 hybrid DVR/NVR, 16ch Audio/Video, up to 16 IPVideo Channels, 6TBStorage,Optional RAID
DHC-20H.264 hybrid DVR/NVR, 20ch Audio/Video, up to 16 IPVideo Channels, 8TBStorage,Optional RAID
DHC-24H.264 hybrid DVR/NVR, 24ch Audio/Video, up to 16 IPVideo Channels, 10TBStorage,Optional RAID
DHC-32H.264 hybrid DVR/NVR, 32ch Audio/Video, up to 16 IPVideo Channels, 12TBStorage,Optional RAID
DHC-40H.264 hybrid DVR/NVR, 40ch Audio/Video, up to 16 IPVideo Channels, 12TBStorage,Optional RAID
DHC-48H.264 hybrid DVR/NVR, 48ch Audio/Video, up to 16 IPVideo Channels, 12TBStorage,Optional RAID
DHC-56H.264 hybrid DVR/NVR, 56ch Audio/Video, up to 16 IPVideo Channels, 12TBStorage,Optional RAID
DHC-64H.264 hybrid DVR/NVR, 64ch Audio/Video, up to 16 IPVideo Channels, 12TBStorage,Optional RAID
