| DISPLAY CONFIGURATION |
| Number of Monitor Outputs | 2 HDMI |
| Output Resolution | 4K or 1080p; independent |
| Monitor Splits | 1, 4, 6, 9, 13, 16 independent on each |
| Aspect Ratio for Splits | 16:9 widescreen or emulate 4:3 |
| Display Contol | Remotely from designated DHX or LWS |
| Local GUI | Basic configuration options via USB mouse and keyboard; access to Linux GUI |
| Aspect ratio | 4:3 |
| DECODING |
| Decode Type | Hardware GPU |
| Compression | H.264 & H.265 |
| Throughput (total for both monitors) | Maximum: 5 ch. @ 8MP/12FPS; 4 ch. @ 3MP/20FPS; real time: 8 ch. @ 1080p real time; 18 ch. @ 720p real time; 32 ch. @ D1
Nominal: 5 ch. @ 8MP; 9 ch. @ 4MP; 13 ch. @ 1080p; 18 ch. @ 720p; 32 ch. @ D1 |
| HARDWARE |
| CPU | Celeron 3855U |
| RAM | 4GB |
| Network Interface | One 10/100/1000 NIC |
| OPERATING SYSTEM |
| Type | 64 Bit Linux CentOS |
| Program and Boot Drive | 32GB mSATA SSD |
| CONNECTORS, INDICATORS, CONTROLS |
| Power | Front Panel LED |
| Power Button | Front panel |
| USB 2.0 | 2 x front panel; 1 x side panel |
| USB 3.0 | 2 x rear panel |
| Power Input | 2.1mm coaxial on rear panel |
| Video Output | 2 x HDMI-A jack on rear panel |
| Network | RJ-45 jack on rear panel |
| Audio | 3.5mm audio in; 3.5mm audio out; both on rear panel |
| POWER |
| Voltage | 12VDC |
| Power Consumption | 12W nominal; 60W max. From supplied 110/220V 50/60Hz 12VDC/5A adapter |
| MECHANICAL |
| Size | 7.87”W x 7.87”D x 2.65”H
(200mm W x 200mm D x 67.3mm H) |
| Weight | 2.2 lbs (1 Kg) |
| SUPPLIED ACCESSORIES |
| | USB mouse; 12VDC/5A power supply; US line cord for power supply; rack ears and screws |
