| UPS | |
| Input Voltage Range | (+/-) 25% at line input |
| Input Frequency | 50/60 Hz |
| Output Voltage | Simulated sine wave at 100V ro 110V/115V/120V or 220V/230V/240V +/-5% |
| Outlets | 6 |
| Battery Run Time | 70 ~ 80 minutes |
| Interface Port | RS-232C Bi-directional communication port |
| Management Software | ✓ |
| Data Line Protection | RJ-45 Modem/Fax protection |
| Surge Energy Rating | 320 J |
| UPS Special | |
| AC Input Capacity on Battery | 1500VA |
| AC Output Voltage Regulation | AVR automatically increase output voltage 15% above input voltage if -9% to -25% of nominal. AVR decrease output voltage 13% below input voltage if +9% to +25% of nominal |
| AC Output Transfer | 2/4 ms, including detection time |
| Protection Spike | 320 J, 2ms |
| Protection EMI/RFI | 10 dB @ 0.15 MHz, 50 dB @ 30 MHz |
| Protection Overload | UPS automatic shutdown if overload exceeds 110% nominal at 60 sec and 130% at 3 sec |
| Protection Unit | Fuse for overload & short circuit protection |
| Protection 10 BaseT | Network (UTP, RJ-45) compatible jacks |
| Protection Short Protection | UPS output cut off immediately or input fuse protection |
| Battery Type | Sealed, Maintenance-free lead acid |
| Battery Typical | 8 hours (to 90% of full capacity) |
| Battery Protection | Automatic self-test & discharge protection, replace battery indicator |
| LED | ✓ |
| Alarm Battery Backup | Slow beeping sound (about 0.47 Hz) |
| Alarm Battery Low | Rapid beeping sound (about 1.82 Hz) |
| Alarm Overload | Continue beeping sound |
| Environment | |
| Operating Temperature | 32 ~ 104° F (0 ~ 40° C) |
| Operating Humidity | ≤ 95% non-condensing |
| Enviornment Ambient | 3,500 meters max. elevation |
| Enviornment Audible | < 40 dBA (1 meter from surface) |
| Environment Storage Condition | ≤ 15,000 m |
| General | |
| Weight | 35 lbs (15.9 kg) |
| Warranty | 5 Years |
